P.P.H. STROBOS The thinnest beacon ramp from Strobos. More
Product code: MONTANA35.DC.CTP-N.160
749 Eur incl. VAT
Specify product selection
Variant does not exist
Expedition 5-7 days. (0 pcs) - Expedition time 5-7 working days!!
P.P.H. STROBOS The thinnest beacon ramp from Strobos. More
Product code: MONTANA35.DC.CTP-N.160

Montana35 beacon ramp blue-orange. Also available in blue, red, white, green and their variants. Also available in dual colors red-blue and orange-red.

Technical parameters:

Light source: 40 up to 120 x 3W LED

Approval: EHK R65, EHK R10, EHK R26, G10

Voltage: 12/24V

Length: 1600mm, height 35mm, depth 210mm

Description and equipment

-LED diodes with a power of 3W

-dual power supply (12/24V)

Accessories

-Control box

-Cable 3m

-Mounting brackets. In addition to the basic type, it is also possible to purchase special mounts for mounting on hagus and crossbars

- Possibility to purchase magnetic or vacuum mounts

Homologation

- The beacon ramp has ECE R65 homologation and meets all requirements of Czech and European legislation for operation on land roads.

- The beacon ramp is marked with homologation labels in accordance with legislation and the manufacturer.

- We have homologation certificates available proving product homologation.

Tip

The owner or operator of the vehicle is always responsible for the vehicle. They are responsible for any possible equipment of the vehicle with warning lights or other components. Before purchasing, find out the legislative requirements for the products in question and make sure that they meet these legislative requirements!

Intended for

This ramp is suitable for all activities requiring warning lights. It is intended for customers who appreciate low consumption and excellent durability of LED technology and a complete package with accessories for installation.

Warning:

Magnetic beacons and ramps are intended primarily for marking stationary vehicles!!! When used while driving, high speed (weather, wind, dirt on the vehicle) may cause the ramp/beacon to fall or be destroyed, which may cause material damage or endanger health and life. The manufacturer or seller bears no responsibility for the magnetic beacon (ramp) used while driving.

Color Orange/blue
Certification ECE R10 covers the approval of vehicles and electrical/electronic equipment with regard to electromagnetic compatibility (EMC). It sets requirements so in-vehicle devices limit electromagnetic emissions and have adequate immunity to interference. ECE R26 covers vehicle approval with regard to external projections, aiming to reduce injury risk from protruding exterior parts. EHK R65 TA1 denotes a Category T (360°) beacon, A = amber, in Class 1 (one standard intensity level). EHK R65 TB1 denotes a Category T (360°) beacon, B = blue, in Class 1 (one standard intensity level).
Voltage 12/24V
Connection type Connection using loose wires. Suitable for connection via your own switches or connection to assemblies.
Mounting type Magnetic mounting – quick, temporary mounting on metal surfaces without drilling. Magnetic beacons are usually equipped with a power cord with a CL plug. Screw mount – a stable installation using screws (typically through a base plate or mounting holes). Best where the beacon is intended to stay permanently installed. Suction cup mount – vacuum cups attach to smooth, non-porous surfaces (e.g., glass or smooth paint). Suitable for temporary use without modifying the vehicle body.
Length 1600 mm
Height 70 mm
Lightbar height without carriers 35 mm
Width 210 mm
Before using the device, carefully read the instructions and follow the warnings, safety information, and recommendations to prevent injury or damage. If possible, test the product and its functionality before installation. Perform the installation with the power disconnected and observe the correct polarity. Check the correct voltage (12/24 V) and use the appropriate fuse. Do not use damaged cables, connectors, or devices. Ensure that the cables are securely fastened and routed away from sharp edges and hot parts of the engine. The lights can be very intense and hot: do not look directly into the light source and do not touch it immediately after operation. Keep out of reach of children and protect from water unless the product is specifically designed for outdoor use. When using on public roads, familiarize yourself with and comply with local regulations. Use the product only for its intended purpose.
Manufacturing company P.P.H. STROBOS
Address Przedsiębiorstwo Produkcyjno Handlowe STROBOS ul. Armii Krajowej4 32-540 Trzebinia NIP: PL628-223-49-81
